APC3588 AI Edge Computing

APC3588-AI is an AI edge computing box designed based on RK3588 processor with rich peripheral resources and complete interfaces, equipped with an octa-core 64-bit CPU, main frequency up to 2.4GHz, integrated ARM Mali-G610 MP4 quad-core GPU, built-in AI accelerator NPU, can provide 6TOPs of computing power.It supports dual network ports, Bluetooth, Wi-Fi, audio/video, camera, 4G SSD hard drive, POE, etc. It supports local communication such as RS232, RS485 UART, CAN, etc., and has various video input and output interfaces. Suitable for intelligent NVR, cloud terminal, industrial control, information release terminal, multimedia advertising machine and other scenes. It is fully functional and convenient:

  • Support 32 channels 1080P 30FPS, support 8K video editing and decoding.
  • Supports LPDDR up to 32GB and EMMC up to 256GB.
  • Supports HDMI® IN video input and USB camera combination.
  • Support Dual HDMI® Output and DP Out(Through Type-C).
  • Support USB3.0/USB2.0/GPIO/CAN/RS485/RS232/TTL peripheral interfaces.
  • Support M.2/SATA3.0/ GTIOT/SPI/ I2C/UART/USB2.0 and other internal expansion
  • Support Tringle Gigabit wired network,
  • Support multiple operating systems: Android13 & Debian11 & Ubuntu
  • Built-in watchdog and RTC battery can support 7*24 hours stable operation.
  • Support AI module build-in(Optional)
Get A Quote
CPU Rockchip RK3588, Quad-core Cortex-A76 and Quad-core Cortex-A55
GPU Mali-G610 MP4 (4x256KB L2 Cache)
AI accelerator 6TOPs NPU + optional Hailo AI accelerator
RAM 4GB LPDDR4(8/16/32GB optional)
ROM 32GB EMMC(64GB/128GB/256GB optional)
Network 3x1000M Ethernet
I/O USB3.0 x 2/USB2.0 x 2/HDMI® OUT x 2/HDMI® IN x 1/SIM Card Slot/TF Slot/DB9 x 2/RS-232 x 2/RS-485 x 2/CAN x 2/GPIO x 6/AC IN
OS Android 13/Debian 11/Ubuntu
Power AC 220V 50Hz
Appearance 247 mm * 230 mm *55mm
Environment Operation temperature: commercial (0°C~ +60℃)/ Extended commercial (-40 °C ~ 85°C), 10%≤Relative humidity≤90%
