EPC1000M

10″ Self-Charging E Ink Spectra 6 Color Photo Frame

Geniatech EPC1000M is a 10″ E Ink Spectra 6 color photo frame built for effortless, low-maintenance operation. Driven by ambient micro-light charging, it reduces dependence on manual recharging. Combining rich, paper-like color performance with simple Wi-Fi and app-based photo updates, it delivers a low-maintenance digital display well suited to retail, hospitality, and corporate environments.

  • 10″ E Ink Spectra 6 color display — paper-like clarity, 1600×1200 / 200 PPI
  • Micro-light powered — recharges from ambient light
  • Up to 160 image updates per charge — minimal field maintenance visits
  • WiFi + mobile app content management — remote updates
  • 6-second upload / 29-second refresh — fast, real-world-ready update cycle
  • Wide operating range (0°C–50°C) — suited to most indoor environments
Model EPC1000M


Dispaly module  Specification which can be used for demo

Screen Size: 10 inchesResolution: 1600×1200

Screen Type: E Ink Spectra 6 E-paper Display

Screen Aspect Ratio: 4:3

Effective Display Area: 203.2×152.4 mm

Supported Display Colors: 6-color display (black/white/red/yellow/blue/green)

PPI: 200





Demo App



Operating System: Android 6.0 and aboveImage Upload Time: 6 seconds

Image Refresh Time: 29 seconds

Image Update Tool: Mobile App (for smartphone)

Languages: Chinese and English

Transmission Method: WiFi





Controller Board Specification

MCU: BL602Memory: 276 KB RAM

Storage: 128 KB, Flash: 4 MB

WiFi: 2.4G

Bluetooth: 5.0



Power Consumption

Battery Capacity: 600mAPower Supply Method: Micro-light Power Supply

Can run maps: 160 times

Working Temperature Operating Temperature: 0℃ ~ 50℃Storage Temperature: -25℃ ~ 60℃
